Build Quality

Build Quality – The Invisible Excellence Behind Every TYNILEM Home

At TYNILEM, we believe that true quality is not just about what you see — but what you feel over time: comfort, durability, thermal efficiency, silence, and safety.

Every TYNILEM house is a result of over 16 years of construction expertise and a commitment to create compact, modern living spaces that meet the highest technical and aesthetic standards.

Regardless of the model, size or layout, all our homes are built with the same structural integrity, energy performance, and long-term vision. Below, we detail the core construction system that sets us apart.

Foundation – Solid from the Ground Up

  • All TYNILEM homes are installed on prefabricated reinforced concrete pads (C25/30 – 40x40x80 cm).

  • For sloped or uneven terrain, foundations are custom-cast on site to ensure perfect balance.

  • The perimeter base is reinforced with concrete blocks for increased stability.

✅ No traditional foundation required – fast installation, terrain adaptability, and portability.

Floor Structure – Industrial Strength with Residential Comfort

  • Made from reinforced concrete beams produced in-house

  • Prefabricated concrete panels between beams for rigidity

  • Finished with leveling screed, 3 cm extruded polystyrene insulation (XPS) and fiber cement board

  • Final interior layer: SPC parquet or ceramic tile

✅ High load resistance, excellent thermal insulation, and long-term comfort underfoot.

Wall System – Our Signature 7-Layer Envelope

Our exterior walls are built using a proprietary 7-layer system, combining modern materials with classic insulation logic:

  1. Travertine-style decorative panel – 20 mm (own production, 50-year tested)

  2. Exterior fiber cement board – 12.5 mm

  3. Galvanized steel profile CW75 mm

  4. Mineral wool insulation – 75 mm, λ = 0.036 W/mK

  5. Interior fiber cement board – 12.5 mm

  6. Fire-resistant gypsum board – 12.5 mm

  7. Interior travertine-style decorative finish – 20 mm

  • Total wall thickness: ~14 cm

  • Fire rating: Class A1 / EI60

  • Thermal U-value: ≈ 0.22 W/m²K

✅ Fireproof, noise-reducing, highly insulated – perfect for year-round comfort.

Roof System – Designed for Extreme Durability

  • Ventilated roofing system with no false ceiling, allowing full vertical space and better air circulation

  • Insulation: 150 mm mineral wool, double vapor barrier

  • Interior finish: natural wooden cladding

  • Exterior finish: standing seam or ribbed zinc-coated metal sheet

  • Thermal U-value: ≈ 0.18 W/m²K

  • Lifespan: 40+ years with minimal maintenance

✅ Elegant, low-maintenance, resistant to weather extremes.

Joinery – Precision and Energy Savings

  • Exterior door: PVC, 70 mm, 5 chambers, Low-E 24 mm glass

  • Windows: fixed or tilt & turn, triple-sealed

  • Frame Uf-value: 1.3 W/m²K, airtightness: Class 4

✅ High-performance joinery that prevents heat loss and increases acoustic insulation.

Installations – Smart, Safe, and Sustainable

  • Electrical: Copper FY cables, solar-ready distribution board with 8 circuits

  • Plumbing: PEX-AL-PEX system, floor drain, optional 50L boiler

  • HVAC: Standard models include inverter air conditioning (9000 BTU)

  • Optional: 1 kW solar panel + 2 kWh battery, underfloor heating, smart control units

✅ Energy-efficient by design, customizable to future-proof your home.

Energy Class & Performance

  • All TYNILEM homes are built to reach Energy Class A or A+, in line with EN ISO 13790

  • NZEB compliant (Nearly Zero Energy Building) for units under 50 m²

  • Estimated yearly energy use: < 35 kWh/m²

✅ Drastically reduced utility bills and increased energy autonomy – ideal for remote living or off-grid use.

Prefabrication & Assembly

  • Homes are built 85% in factory-controlled conditions, ensuring consistency and quality

  • On-site assembly by a specialized 5-person team in 3 to 10 working days, depending on model

  • Weather delays are minimal due to prefabrication

  • Transport and installation are coordinated in detail, across Europe and the UK

✅ Fast, efficient, and predictable delivery with top-level finishing.

Durability & Warranty

  • Structural lifespan: 50+ years

  • 20-year warranty on structural integrity

  • All components certified and tested to European building standards

✅ Not just a house — a long-term investment, built to endure.

Eco-Friendly Construction Philosophy

  • Use of recyclable, low-impact materials

  • Minimal on-site waste thanks to factory assembly

  • Infrastructure designed to support solar energy and future tech upgrades

  • Transport-optimized logistics for smaller CO₂ footprint

✅ Designed for a lifestyle that respects both nature and modern living.

 Whether you choose the Terace, Deluxe, Cremole, or Travertino model, the core of your home remains the same: a TYNILEM structure — strong, smart, sustainable.
